Magnets for DC motors
 |
|
|
Type |
Br
Residual Flux Density |
Hcb
Coercive Force |
Hcj
Intrinsic Coercive force |
(BH)max max. Energy Product |
|
mT |
KGs |
KA/m |
KA/m |
KA/m |
KOe |
KJ/m 3 |
MGOe |
| Y10T |
200 ~ 235 |
2.0 ~ 2.35 |
125 ~ 160 |
1.57 ~ 2.01 |
210 ~ 280 |
2.64 ~ 3.52 |
6.5 ~ 9.5 |
0.8 ~ 1.2 |
| Y20 |
320 ~ 380 |
3.2 ~ 3.8 |
135 ~ 190 |
1.70 ~ 2.38 |
140 ~ 195 |
1.76 ~ 2.45 |
18.0 ~ 22.0 |
2.3 ~ 2.8 |
| Y22H |
310 ~ 360 |
3.1 ~ 3.6 |
220 ~ 250 |
2.77 ~ 3.14 |
280 ~ 320 |
3.52 ~ 4.02 |
20.0 ~ 24.0 |
2.5 ~ 3.0 |
| Y23 |
320 ~ 370 |
3.2 ~ 3.7 |
170 ~ 190 |
2.14 ~ 2.38 |
190 ~ 230 |
2.39 ~ 2.89 |
20.0 ~ 25.5 |
2.5 ~ 3.2 |
| Y25 |
360 ~ 400 |
3.6 ~ 4.0 |
135 ~ 170 |
1.70 ~ 2.14 |
140 ~ 200 |
1.76 ~ 2.51 |
22.5 ~ 28.0 |
2.8 ~ 3.5 |
| Y26H |
360 ~ 390 |
3.6 ~ 3.9 |
220 ~ 250 |
2.77 ~ 3.14 |
225 ~ 225 |
2.83 ~ 3.21 |
23.0 ~ 28.0 |
2.9 ~ 3.5 |
| Y27H |
370 ~ 400 |
3.7 ~ 4.0 |
205 ~ 250 |
2.58 ~ 3.14 |
210 ~ 225 |
2.64 ~ 3.21 |
25.0 ~ 28.0 |
3.1 ~ 3.7 |
| Y30 |
370 ~ 40 |
3.7 ~ 4.0 |
175 ~ 210 |
2.20 ~ 2.64 |
180 ~ 220 |
2.26 ~ 2.77 |
26.0 ~ 30.0 |
3.3 ~ 3.8 |
| Y30BH |
380 ~ 390 |
3.8 ~ 3.90 |
223 ~ 235 |
2.80 ~ 2.95 |
231 ~ 245 |
2.90 ~ 3.08 |
27.0 ~ 30.0 |
3.4 ~ 3.7 |
| Y30-1 |
380 ~ 400 |
3.8 ~ 4.0 |
230 ~ 275 |
2.89 ~ 3.46 |
235 ~ 290 |
2.95 ~ 3.65 |
27.0 ~ 32.0 |
3.4 ~ 4.0 |
| Y20-2 |
395 ~ 415 |
3.95 ~ 4.15 |
275 ~ 300 |
3.46 ~ 3.77 |
310 ~ 335 |
3.90 ~ 4.21 |
28.5 ~ 32.5 |
3.5 ~ 4.0 |
| Y32 |
400 ~ 420 |
4.0 ~ 4.2 |
160 ~ 190 |
2.01 ~ 2.38 |
165 ~ 195 |
2.07 ~ 2.45 |
30.0 ~ 33.5 |
3.8 ~ 4.2 |
| Y33 |
410 ~ 430 |
4.1 ~ 4.3 |
220 ~ 250 |
2.77 ~ 3.14 |
225 ~ 255 |
2.83 ~ 3.21 |
31.5 ~ 35.0 |
4.0 ~ 4.4 |
| Y35 |
400 ~ 410 |
4.00 ~ 4.10 |
175 ~ 195 |
2.20 ~ 2.45 |
180 ~ 200 |
2.26 ~ 2.51 |
30.0 ~ 32.0 |
3.8 ~ 4.0 |
