MW-1A-21 Semiautomatic Auger Filling Machine
| Metering Mode | Auger rotation filling traced by weighing feedback |
| Filling Weight | 1 �� 500g (The screw attachment is to be changed) |
| Filling Accuracy | Package weight �� 100g,with an error<2% |
| 100 �� 500g, with an error�ܡ�1% | |
| Filling Rate | 40 - 120 times/min |
| Power Supply | 3P / 220V-415V 50-60Hz |
| Total Power | 1.1KW |
| Total Weight | 130Kg |
| Overall Dimensions | 800��790��1800mm |
| Hopper Volume | 22L (35L for oversized hopper) |
Desciptive abstract:
This type can do measuring and filling work. Due to the special design, so it fits more to the fluidic or low-fluidity materials, like milk powder, Albumen powder ,solid drink, white sugar, dextrose, coffee powder, fodder, pharmaceuticals, agriculture pesticide, granular additive, dyestuff, and so on.
Main features :
- There is no limit of packaged container. It is widely used invariable materials and package-weight specifications.
- The surface of whole machine is made by stainless steel material except of motor. Knockdown transparent hopper, which could be washed without toolings.
- weight feedback to run after the specific weight, overcome the shortcoming of the net weight change with the material specific-weight.
- Servo motor driving screw is characteristics of no easy abrasion, high-precision orientation, setup rotate speed, stable performance
- LCD simply visual supervisory. Stepless adjust the net weight. Change the working parameter at any time, easy to control.Change the working parameter at any time, easy to control.
- Save the parameter of each product to later use. 10 recipes of magistral fomula save at the most.
- Fit for lots of material range from fine-powder to coarse-granule, if change the auger attachment. Dust- collector set on dust material situation to absorb dust spout out.
