MW-1B-423 Semiautomatic Auger Filling Machine
| Metering Mode | Auger rotation filling traced by weighing feedback |
| Packaging Weight | 10 - 5000g(The screw attachment is to be changed) |
| Packaging Accuracy | �� 100g, �ܡ�2%;100 - 500g,�ܡ�1%; ��500g,�ܡ�0.5% |
| Filling Rate | 40 - 120 times/min |
| Power Supply | 3P /208 -415V 50-60Hz |
| Total Power | 1.5KW |
| Total Weight | 260kg |
| Overall Dimensions | 1140��970��2200mm |
| Hopper Volume | 50L(oversized hopper65L) |
Descriptive abstract:
This type can do measuring and filling work. Due to the special design, so it fits more to the liquid or low-fluidity materials, like milk powder, albumen powder, solid drink, white sugar, dextrose, coffee powder, pharmaceuticals, granular additive, dyestuff, and so on.
Main features:
- The surface of whole machine is made by stainless steel material.
- Unlock transparent hopper, which could be washed without toolings.
- Servo motor driving screw.
- PLC & Touch screen control.
- Include handwheel of adjustable height.
- Save the parameter of each product to later use. 7 recipes of magistral fomula save at the most.
- Fit for lots of material range from fine-powder to coarse-granule, if change the screw attachment. Dust- collector set on dust material situation to absorb dust spout out.
