MW- Series Dry Powder Mixer
Model | MW-200 | MW-300 | MW-500 | MW-1000 | MW-1500 |
Effective Vomume | 200L | 300L | 500L | 1000L | 1500L |
All Volume | 280L | 420L | 710L | 1420L | 1800L |
Time | 0-30 min | 0-30 min | 0-30 min | 0-30 min | 0-30 min |
Overall Dimension(m) | 1.3��0.68��1.4 | 1.4��0.78��1.53 | 1.64��0.94��1.8 | 1.96��1.13��2.0 | 2.38��1.24��1.85 |
Total Power | 1.5kw | 2.2kw | 3kw | 5.5kw | 7.5kw |
Power Supply | 3 Phase 208-415V 50/60Hz |
Descriptive abstract:
The Horizontal Screw Belt Mixer is a new type, high efficiency mixing equipment, are widely used in food and chemical industry.
Main features:
- Horizontal tube body, inner & outer dual screw with special structure, running stable, best quality, low noise, long life, convenient installation, widly usage, with many kind of mixer structure, multiple function
- Whole machine except for motor is made of stainless steel
- With warm sheet, bearing great pressure, make easy-forming material into difficult forming after filling steam
- For different mixing requirements, use different screw structure, rapid & thorough mixing
- There is a split window in the body for cleaning
- Load coefficient large, covering small surface
