MW-2A-1 Automatic Auger Filling Machine

Metering Mode Auger rotation filling
Packaging Weight 1 ~ 500g
Packaging Accuracy �� 100g, �ܡ�2%; 100 ~ 500g, �ܡ�1%
Filling Speed 15 - 60 bottles/min
Power Supply 3P /208 - 415V 50/60Hz
Total Power 1.2KW
Air Supply 6kg/cm2; 0.05m3/min
Total Weight 160Kg
Overall Dimensions 1500��760��1850mm
Hopper Volume 35L

Descriptive abstract:

The Model MW-2A-1 is a complete, economical solution to your filling production line requirements. Can measuring and filling powder and granule. It consists of the Filling Head, an independent motorized chain conveyor mounted on a sturdy, stable frame base, and all necessary accessories to reliably move and position containers for filling, dispense the required amount of product, then quickly move the filled containers away to other equipment in your line (e.g., cappers, labelers, etc.).it fits more to the fluidic or low-fluidity materials, like milk powder, albumen powder, solid drink, white sugar, dextrose, coffee, fodder, pharmaceuticals, agriculture pesticide, granular additive, dyestuff, and so on.

Main features:

Optional devices:
